H07RN-FEN 50525-2.21 / IEC 60245-4
Heavy Rubber Sheathed Flexible Cable H07RN-F
450/750 V oil-resistant rubber cable for heavy service — construction sites, agriculture, generators and portable equipment.
Type
Heavy rubber sheathed flexible cable
Standard
EN 50525-2.21 / IEC 60245-4
Voltage Rating
450/750 V
Conductor
Class 5 fine-wire bare copper
Jacket
EPR/CR rubber sheath
- ✓VDE/CE approved to EN 50525-2.21 (H07RN-F)
- ✓450/750 V, rubber insulated and sheathed
- ✓Oil-resistant, weather-resistant, abrasion-resistant
- ✓Flexible down to -25 °C — ideal for outdoor and rough service
- ✓Used for generators, pumps, welders, construction and agricultural equipment
- ✓2–5 cores, 1.0–6 mm² (larger sizes on request)
Full Specifications
Overview
Type
Heavy rubber sheathed flexible cable
Standard
EN 50525-2.21, IEC 60245-4 (H07RN-F)
Rated Voltage
450/750 V
Rated Temperature
60 °C (max conductor temperature)
Application
Generators, pumps, welders, construction sites, agriculture, ports
Core Configurations
2G, 3G, 4G, 5G × 1.0–6 mm²
Construction
Conductor
Class 5 fine-wire bare copper per EN 60228
Insulation
EPR rubber
Sheath
CR (chloroprene) rubber, black
Core Identification
Harmonized color code
Weather Resistance
UV- and ozone-resistant sheath
Electrical Performance
Voltage Test
3 kV AC, 5 min
Flex Life
High — designed for continuous flexing
Cold Flexibility
Operates down to -25 °C
Oil Resistance
Per EN 50525-2.21
Packaging
Standard Length
50 m, 100 m coils; drum lengths on request
Packaging
Coil, carton or wooden drum
Certifications
VDE, CE, RoHS, REACH
Specifications are indicative for the standard configuration and subject to change with continuous product improvement. Confirm final parameters with our sales team for your order.
